ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes

جزئیات محصول:

محل منبع:	چین
نام تجاری:	YUHONG
گواهی:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
شماره مدل:	ASME SB163

پرداخت:

مقدار حداقل تعداد سفارش:	500 کیلوگرم
قیمت:	Depend
جزئیات بسته بندی:	پرونده ply-wooden
زمان تحویل:	30-65 روز
شرایط پرداخت:	T/T، L/C
قابلیت ارائه:	1000 تن در ماه

مخاطب

همه محصولات

لوله بدون درز از جنس استنلس استیل (290)

لوله بدون درز از جنس استنلس استیل (277)

لوله فولادی ضد زنگ دوبلکس (127)

لوله فولادی ضد زنگ دوبلکس (29)

لوله سوزن (107)

لوله باله (631)

مبدل حرارتی (17)

لوله مبدل حرارتی (424)

بسته لوله مبادله گرما (37)

صفحه لوله مبدل حرارتی (116)

بافل مبادله گرما (36)

کولر (8)

مخازن تحت فشار (4)

لوله جوش داده شده از جنس استنلس استیل (57)

لوله جوش داده شده از جنس استنلس استیل (114)

آلیاژ نیکل لوله (261)

لوله آلیاژ نیکل (79)

لوله آلیاژ مس (227)

لوله فولادی آلیاژی (184)

لوله تیتانیومی (10)

لوله آنیل روشن (153)

لوله دیگ بخار (145)

اتصالات فولادی (804)

فلنج فولادی (590)

دیگران (391)

قطعات پوشش (7)

توضیحات محصول جزئیات

محصول:	کندانسورها و لوله های مبدل حرارتی	کندانسور و مبدل حرارتی لوله مواد:	آلیاژ نیکل
استاندارد لوله های کندانسور و مبدل حرارتی:	ASME SB163	درجه لوله کندانسور و مبدل حرارتی:	N02201
کاربرد لوله های کندانسور و مبدل حرارتی:	مبدل های حرارتی / بویلر / کندانسور و غیره	بسته بندی لوله های کندانسور و مبدل حرارتی:	پرونده ply-wooden
برجسته کردن:	ASME SB163 nickel alloy tubes,N02201 seamless condenser tubes,nickel alloy heat exchanger tubes , N02201 seamless condenser tubes , nickel alloy heat exchanger tubes

ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes

YUHONG Group can offer ASTM B163 / ASME SB163 N02201 SMLS nickel alloy tubes.

ASTM B163 / ASME SB163 is the standard specification for seamless nickel and nickel-alloy condenser and heat-exchanger tubes. N02201 (Alloy 201) likes N02200, it's a commercially pure nickel (99.0% min) known for its excellent resistance to corrosion, particularly in caustic environments, and its high thermal and electrical conductivity. Its seamless nature ensures reliability under pressure and in corrosive service.N02201 resists corrosion in a wide range of reducing and neutral media, including fresh water, natural waters, non-oxidizing salts, and alkaline solutions. It is particularly resistant to caustic alkalies.

N02201 maintains good strength and ductility from cryogenic temperatures up to moderately high temperatures. Alloy 201 has very low carbon content (<0.02%), which prevents carbide precipitation (sensitization) during welding and service, preserving its corrosion resistance in the heat-affected zones.

ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes 0

Chemical Composition % Alloy 201 / UNS N02201

Nickel	Copper	Iron	Manganese	Carbon	Silicon	Sulfur
99.0 min	0.25 max	0.40 max	0.35	0.02max	0.35	0.01
Nickel element shall be determined arithmetically by difference.

Mechanical Property Alloy 201 / UNS N02201

Condition	Tensile Strength min	Yield Strength min	Elongation (%)	Rockwell Hardness
Annealed	50ksi (345MPa)	28ksi (193MPa)	40 min.	/
Stress-relieved	60ksi (414MPa)	55ksi (379MPa)	15 min.	B62 max

SB163 N02201 tubes common applications include:

Caustic Evaporators and Concentrators
Tubes are used in heat exchangers that concentrate sodium hydroxide (NaOH) or potassium hydroxide (KOH) solutions from weak concentrations to 50% or even 73%. Stainless steel would corrode catastrophically in this service.

Chemical Processing Industry (CPI)
1.Organic Chlorination Processes: Handling chlorinated hydrocarbons and associated by-products like HCl.
2.Production of Plastics and Synthetic Fibers: Where corrosive catalysts or intermediates are present.
3.Fine Chemical and Pharmaceutical Synthesis: For reactors and heat exchangers handling aggressive media where purity is critical (nickel ions are less problematic than corrosion products from other metals).

Power Generation & Marine
1.Feedwater Heaters in Advanced Plants: Where water chemistry is highly controlled, and reliability is paramount.
2.Specialized Condensers: In geothermal plants or in coastal/offshore facilities where cooling water is highly aggressive, brackish, or polluted, and where chlorination is used for biofouling control.

Other Specialized Applications
1.HF Alkylation Units in oil refineries (for handling hydrogen fluoride).
2.Production and Handling of Fluorine and Fluorinated Compounds.
3.Sea Water Desalination Plants, particularly in the high-temperature brine heaters and sections with high chloride concentration.

Testing and Inspection

Hydrostatic Test (or Nondestructive Electric Test)

Flattening Test,Reverse Flattening Test

Flaring Test

Hardness Test

Tension Tests

Chemical Analysis
